HY-P345 temperature and pressure integrated transmitter

Sensor

The HY-P345 temperature and pressure integrated transmitter is a transmitter that simultaneously measures temperature and pressure. This product uses a resistive pressure sensor with stainless steel isolation film as the pressure signal measurement element, a high-precision platinum resistance as the temperature measurement element, and a dedicated pressure and temperature signal processing circuit to convert the signal of the measurement element into a standard current or digital signal output.

The HY-P345 temperature and pressure integrated transmitter is widely used in situations where temperature and pressure are measured simultaneously.

Features:

Simultaneous measurement of temperature and pressure, and output independent temperature and pressure signals

All-stainless steel, all-welded structure, strong media compatibility

Small size and lightweight

Stable and reliable performance

Product Applications

Petrochemical

Measurement and control technology

Hydraulics and pneumatics

Technical parameters

Range	0kPa ~10kPa... 10MPa (Pressure)
Range	-40~85°C (temperature)
overload	1.5 times full-scale pressure
Power supply range	Power supply 10~28VDC
Output signal	4~20mADC
Output signal	RS485 (Modbus-RTU)
precision	±0.5%FS (pressure); ±2°C (Temperature Type I)±0.5°C (Temperature Type II)
Insulation resistance	100MΩ@250VDC
Operating temperature	-40°C~85°C
Storage temperature	-40oC~120oC
Long-term stability	0.2%FS/year
vibration	10g@20Hz.... 2000Hz
Media suitability	Non-corrosive to stainless fluoroxibe for all kinds of fluids
Mechanical shock	100g@11ms
Pressure connection	G1/4 or customized
